Heating Circulator
RT~300℃
Product Introduction
YUC series heating circulator takes oil electric heating system with a totally enclosed structure, which is designed no oil mist volatilization with high temperature, , large flow rate and high lift. The circulating pump outputs the heat-conducting fluid to heat the materials of the supporting equipment, and it is widely used as a combination device in biopharmaceutical, petrochemical, medical and health, food and other industries that need high temperature environment.
Application Fields
Product Advantages
Side inlet, side exhaust, rounded corner design, install casters, more convenient to move.
Level visualization.
Explosion proof and water cooling(Optional).
Touch button, easy operation. with drain port for easy discharge of waste liquid.
Equipped with an exhaust valve, which can eliminate the cause in time.Gas escaping when the system medium heats up.
Model | YUC-3020 | YUC-5020 | YUC-10020 | YUC-15020 | YUC-25020 | YUC-38020 | YUC-600020 |
|---|---|---|---|---|---|---|---|
65℃-Cooling
Capacity
（KW） | 0.6 | 1.8 | 3.4 | 5 | 8.5 | 12 | 19 |
100℃-Cooling
Capacity
（KW） | 2 | 4 | 8 | 12 | 20 | 30 | 48 |
200℃-Cooling
Capacity
（KW） | 3.5 | 5.5 | 10 | 15 | 25 | 38 | 60 |
Heating Power（KW） | 3 | 5 | 10 | 15 | 25 | 38 | 60 |
Expansion Tank Volume（L） | 3.9 | 3.8 | 19 | 35 | 65 | 90 | 160 |
Safety Protection | Self-diagnosis; High pressure switch; Overload relay; Thermal protection device; | Self-diagnosis; High pressure switch; Overload relay; Thermal protection device; | Self-diagnosis; High pressure switch; Overload relay; Thermal protection device; | Self-diagnosis; High pressure switch; Overload relay; Thermal protection device; | Self-diagnosis; High pressure switch; Overload relay; Thermal protection device; | Self-diagnosis; High pressure switch; Overload relay; Thermal protection device; | Self-diagnosis; High pressure switch; Overload relay; Thermal protection device; |
Water Cooler | Plate Heat Exchanger | Plate Heat Exchanger | Plate Heat Exchanger | Plate Heat Exchanger | Plate Heat Exchanger | Plate Heat Exchanger | Plate Heat Exchanger |
Cooling Method | water cooling | water cooling | water cooling | water cooling | water cooling | water cooling | water cooling |
Temp Sensor | PT100 | PT100 | PT100 | PT100 | PT100 | PT100 | PT100 |
Heating Method | electric heating | electric heating | electric heating | electric heating | electric heating | electric heating | electric heating |
Total Power（Kw） | 3.8 | 5.9 | 11 | 16.5 | 26.5 | 41 | 63 |
Frequency（HZ） | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
Voltage（V） | 220，1P | 220V,1P/3P 380V,3P | 220/380/480V,3P | 220/380/480V,3P | 220/380/480V,3P | 220/380/480V,3P | 220/380/480V,3P |
Optimum Ambient Humidity | 45~80%RH | 45~80%RH | 45~80%RH | 45~80%RH | 45~80%RH | 45~80%RH | 45~80%RH |
Ambient Temp（℃） | 5~30 | 5~30 | 5~30 | 5~30 | 5~30 | 5~30 | 5~30 |
Temp Range（℃) | RT~200；±0.5 | RT~200；±0.5 | RT~200；±0.5 | RT~200；±0.5 | RT~200；±0.5 | RT~200；±1 | RT~200；±1 |
Model | YUC-3030 | YUC-5030 | YUC-10030 | YUC-15030 |
|---|---|---|---|---|
65℃-Cooling
Capacity
（KW） | 0.6 | 1.8 | 3 | 4 |
100℃-Cooling
Capacity
（KW） | 1.4 | 4 | 7 | 10 |
200℃-Cooling
Capacity
（KW） | 2.5 | 5 | 9 | 13 |
300℃-Cooling
Capacity
（KW） | 3 | 5 | 10 | 15 |
Heating Power（KW） | 3 | 5 | 10 | 15 |
Expansion Tank Volume（L） | 3.8 | 3.8 | 19 | 50 |
Safety Protection | Self-diagnosis; High pressure switch; Overload relay; Thermal protection device; | Self-diagnosis; High pressure switch; Overload relay; Thermal protection device; | Self-diagnosis; High pressure switch; Overload relay; Thermal protection device; | Self-diagnosis; High pressure switch; Overload relay; Thermal protection device; |
Water Cooler | Plate Heat Exchanger | Plate Heat Exchanger | Plate Heat Exchanger | Plate Heat Exchanger |
Cooling Method | water cooling | water cooling | water cooling | water cooling |
Temp Sensor | PT100 | PT100 | PT100 | PT100 |
Heating Method | electric heating | electric heating | electric heating | electric heating |
Total Power（Kw） | 4.2 | 6.2 | 11.5 | 15.9 |
Frequency（HZ） | 50/60 | 50/60 | 50/60 | 50/60 |
Voltage（V） | 220，1P | 220V,1P/3P 380V,3P | 220/380/480V,3P | 220/380/480V,3P |
Optimum Ambient Humidity | 45~80%RH | 45~80%RH | 45~80%RH | 45~80%RH |
Ambient Temp（℃） | 5~30 | 5~30 | 5~30 | 5~30 |
Temp Range（℃) | RT~300；±0.5 | RT~300；±0.5 | RT~300；±0.5 | RT~300；±0.5 |
